DIOSHY TPE - Chemical Innovation Co.,Ltd.

TPEs are materials that have mechanical properties similar to rubber but it can be processed by methods designed for standard thermoplastics such as extrusion and injection molding. They can be recycled much more easily and efficiently. There are varieties types of TPE such as SEBS, SBS, SEBS/SBS, TPO, TPV, TPU and TPEE.

Advantage of TPE :

Board hardness range (10 ShoreA – 70 ShoreD).
Excellent touch feeling can be used to replace conventional rubber and silicone.
They are conforming to FDA ,RoHS and REACH.
The main application is moulding with other types of plastic such as PE, PP, GPPS, HIPS, ABS, PC, PC/ABS, PETG and etc.

Applications :

Automotive parts
Housewares
Toys
Sporting goods
Footwear

Chemical name:Thermoplastic Elastomer (TPE)

Selection Guide

Grade	Series	Specific gravity, g/cm 3	Hardness (Shore A)	Hardness (Shore D)	Melt index (190°C, 2160 g), g/10min	100% Modulus, Kg/mm 2	300% Modulus, Kg/mm2	Tensile strength, Kg/mm2	Elongation at break, %	Tear strength, Kg/mm	Compression set 23°C/22hrs, %	TPS type	Color	Temperature, °C: Injection (Nozzle)	Temperature, °C: Extrution (Nozzle)	Glass transition point, °C
HP-907NC	SEBS	0.918	45	-	7.92	0.09	0.06	0.35	690	1.92	13	SEBS&SBS	White	195-205	-	-
HP-915NC	SEBS	0.916	55	-	13.8	0.11	0.07	0.35	622	2.24	13	SEBS&SBS	White	195-205	-	-
HP-930NC	SEBS	1.083	30	-	34.86	0.05	0.03	0.18	693	0.98	9	SEBS&SBS	White	185-195	-	-
GP-945	SEBS	1.063	45	-	10.32	0.07	0.05	0.26	633	1.71	15	SEBS&SBS	White	195-205	-	-
GP-955	SEBS	1.06	55	-	40.6	0.11	0.06	0.24	489	1.67	23	SEBS&SBS	White	195-205	-	-
GP-965	SEBS	1.057	65	-	28.54	0.15	0.08	0.32	472	2.11	26	SEBS&SBS	White	195-205	-	-
GP-975	SEBS	1.057	75	-	35.8	0.15	0.09	0.34	486	2.57	24	SEBS&SBS	White	195-205	-	-
GP-985	SEBS	1.055	80	30	38.64	0.26	0.12	0.41	466	3.57	34	SEBS&SBS	White	195-205	-	-
GP-995	SEBS	1.052	90	45	28.32	0.5	0.21	0.79	533	6.44	24	SEBS&SBS	White	195-215	-	-
MP-910	SBS	0.858	5	-	64.12	0.01	0.01	0.1	938	0.64	10	SBS	Translucent	185-195	-	-
MP-930NC	SBS	0.9	30	-	-	0.04	0.03	0.3	629	1.24	10	SBS	Translucent	185-195	-	-
MP-830	SBS	1.077	30	-	32.14	0.07	0.04	0.27	784	1.61	11	SBS	White	185-195	-	-
MP-845	SBS	1.105	45	-	79.66	0.11	0.05	0.18	492	1.51	14	SBS	White	195-205	180-195	-
MP-855	SBS	1.039	55	-	29.92	0.12	0.06	0.26	591	1.88	16	SBS	White	195-205	180-195	-
MP-865	SBS	1.026	65	-	34.68	0.17	0.08	0.27	432	2.19	18	SBS	White	195-205	180-195	-
MP-875Q	SBS	1.006	75	-	17.82	0.23	0.11	0.41	463	3.31	16	SBS	White	195-205	190-205	-
MP-885	SBS	1.007	85	35	22.2	0.31	0.13	0.39	312	3.28	32	SBS	White	195-205	190-205	-
MP-890PTA	SBS	1.095	90	40	20.76	0.46	0.18	0.55	360	4.65	28	SBS	White	195-215	195-215	-
AB-820EM	SEBS Alloy	1.118	20	-	29.7	0.04	0.03	0.019	817	1.01	10	SEBS-U	White	185-195	185-195	-
AB-835EM	SEBS Alloy	1.082	35	-	9	0.07	0.05	0.28	807	2.33	11	SEBS-U	White	190-205	180-195	-
AB-845EM	SEBS Alloy	1.098	45	-	5.16	0.14	0.08	0.28	496	2.42	11	SEBS-U	White	190-205	180-195	-
AB-855EM	SEBS Alloy	1.095	55	-	7.06	0.19	0.11	0.38	569	3.32	15	SEBS-U	White	190-205	180-195	-
AB-865EM	SEBS Alloy	1.094	65	-	7.5	0.23	0.13	0.54	672	3.9	13	SEBS-U	White	190-205	180-195	-
AB-875EM	SEBS Alloy	1.092	75	-	11.04	0.23	0.12	0.48	626	3.97	15	SEBS-U	White	195-205	190-205	-
AB-885EM	SEBS Alloy	1.097	85	35	-	0.45	0.21	0.7	434	6.18	21	SEBS-U	White	195-205	190-205	-
AB-890AM-1	SEBS Alloy	1.15	90	40	-	0.71	0.27	0.84	374	8.07	19	SEBS-U	White	195-215	195-215	-
NL-860(10)	SEBS Alloy	1.175	60	-	2.4	0.13	0.08	0.65	635	2.78	18	SEBS-U	White	190-205	180-195	-
UL-860KM	SEBS (Specialized)	1.297	60	-	6.66	0.12	0.05	0.41	739	1.72	16	SEBS-O	White	195-230	-	-
UL-875KM	SEBS (Specialized)	1.227	75	-	1.92	0.13	0.05	0.37	640	2.14	19	SEBS-O	White	195-230	-	-
GP-845CN-1	SEBS (Specialized)	1.27	45	-	16.68	0.08	0.05	0.52	763	1.86	15	SEBS-M	White			-
FP-820	SEBS (Specialized)	1.205	30	-	1.86	0.04	0.03	0.3	827	1.9	5	SEBS	White	195-205	-	-
HG-790TDO-1	SEBS (Specialized)	1.109	95	-	-	0.81	0.26	0.81	300	10.17	-	SEBS-C	Black	195-205	190-230	-
HG-795-10-4	SEBS (Specialized)	1.094	95	50	6.12	0.34	0.14	0.41	389	4.28	-	SEBS-C	Black	195-205	190-230	-
SP-690NEW	SEBS (Specialized)	0.98	95	50	4.26	0.25	0.14	0.62	95	3.25	-	SEBS-W	-	130	-	-
SP-595W	SEBS (Specialized)	0.973	95	50	8.16	0.41	0.36	0.5	112	4.84	-	SEBS-W	-	200	-	-
TPO F950-OS	TPO	0.884	50	-	9.42	0.12	0.06	0.42	759	2.35	-	TPO-I	Translucent	185-195	-	-
TPO F970-OS	TPO	0.875	70	-	12.24	0.18	0.08	0.45	974	3.53	19	TPO-I	Translucent	195-205	180-195	-
TPO F980-OS	TPO	0.881	80	-	9.96	0.28	0.11	0.46	929	4.49	21	TPO-I	Translucent	195-205	180-195	-
TPO F990-OS	TPO	0.888	90	45	6.06	1.1	0.35	1.18	730	13.17	23	TPO-I	Translucent	195-205	190-205	-
TPO F995-OS	TPO	0.888	95	50	6.42	1.07	0.34	1.18	787	12.47	28	TPO-I	Translucent	195-205	190-205	-
TPO F955D-OS	TPO	0.891	-	55	6.72	1.1	0.37	1.36	784	13.57	32	TPO-I	Translucent	185-195	-	-
TPO F963D-OS	TPO	0.895	-	63	7.62	1.28	1.03	2.12	131	17.53	34	TPO-I	Translucent	195-205	180-195	-
VP-830	TPV	0.966	30	-	19.14	0.05	0.04	0.24	513	1.22	26	TPV-S	White	185-195	-	-
VP-840	TPV	0.947	40	-	10.86	0.08	0.06	0.25	448	1.28	17	TPV-S	White	195-205	180-195	-
VP-850	TPV	0.922	50	-	3.48	0.12	0.09	0.39	463	2.06	14	TPV-S	White	195-205	180-195	-
VP-860	TPV	0.955	60	-	3.66	0.21	0.12	0.46	453	2.37	11	TPV	White	195-205	180-195	-
VP-870	TPV	0.959	70	-	8.04	0.21	0.11	0.46	519	3.18	8	TPV	White	195-205	190-205	-
VP-870	TPV	0.943	80	-	6.48	0.36	0.18	0.71	491	5.13	19	TPV	White	195-205	190-205	-
VP-890	TPV	0.898	90	40	14.46	0.248	0.21	0.85	491	6.01	24	TPV	White	195-205	190-205	-
VP-895	TPV	0.886	95	50	10.32	0.66	0.27	1.08	537	8.2	26	TPV	White	195-205	195-215	-
VP-865HD-2	TPV	0.923	65	-	2.4	0.17	0.11	0.62	603	3.36	15	TPV-O	White	195-205	180-195	-
TPU T980M	TPU	1.21	80	-	-	50	-	350	700	95	-	-	-	185-195	170-185	-45
TPU T990M	TPU	1.22	90	-	-	100	-	400	600	140	-	-	-	195-205	180-195	-43
TPU T998M	TPU	1.23	98	53	-	170	-	500	550	170	-	-	-	195-205	190-205	-39
TPU T960DM	TPU	1.23	-	60	-	185	-	500	500	180	-	-	-	195-215	195-215	-23
TPU E980M	TPU	1.21	80	-	-	50	-	410	700	95	-	-	-	185-195	170-185	-45
TPU E990M	TPU	1.22	90	-	-	100	-	440	600	140	-	-	-	195-205	180-195	-43
TPU E998M	TPU	1.23	98	53	-	170	-	460	550	170	-	-	-	195-205	190-205	-39
TPU T995NC	TPU	1.22	95	46	-	115	-	450	550	155	-	-	-	-	-	-
TPU T995NCS	TPU	1.22	95	46	-	110	-	450	550	145	-	-	-	-	-	-
TPEE E930D-GS	TPEE	1.062	80	30	11.16	0.43	0.2	1.04	779	9.05	2	TPC-ET	White	205-215	195-205	-
TPEE E940D-GS	TPEE	1.129	95	40	11.46	0.84	0.2	1.66	908	14.07	3	TPC-ET	White	205-215	195-205	-
TPEE E955D-GS	TPEE	1.197	97	55	-	1.44	0.51	2.76	698	22.94	16	TPC-ET	White	225-235	210-220	-
TPEE E963D-GS	TPEE	1.233	-	53	-	1.97	0.65	3.2	541	25.77	21	TPC-ET	White	-	-	-
TPEE E972D-GS	TPEE	1.266	-	72	-	2.75	1.9	3.01	227	29.41	30	TPC-ET	White	225-235	215-225	-
TPEE E940D-HD	TPEE	1.12	93	40	-	0.75	0.29	1.43	867	12.79	20	TPC-ET	White	205-215	195-205	-
TPEE E955D-HD	TPEE	1.185	96	55	-	1.35	0.48	3.54	861	22.51	27	TPC-ET	White	225-235	210-220	-
TPEE E963D-HD	TPEE	1.208	-	63	-	1.69	0.58	3.47	697	25.14	21	TPC-ET	White	225-235	215-225	-
